Description
- Variety of bezel and color options with aesthetic design.
- Mounting depth less than 46.8 mm below panel.
- Up to 6 contact blocks (3 contact blocks across and 2 rows deep).
- Symmetrical contact block.
- Push-in Plus terminal block type.
- Snap-in switch unit for quick and easy mounting.
Specifications:
| Attribute | Value |
| Push Button Color | Green, Red |
| Cutout Diameter | 22mm |
| Series | A22N |
| Push Button Actuation | Momentary |
| Contact Configuration | 2NO/NC |
| Push Button Style | Round |
| IP Rating | IP66 |
| Maximum AC Voltage | 440V |
| Maximum DC Voltage | 24V |
| Mounting Type | Panel Mount |
| Push Button Diameter | 28.8mm |
| Terminal Type | Screw |
| Minimum Operating Temperature | -25°C |
| Maximum Current | 10A |
| Push Button Material | Plastic |
| Maximum Operating Temperature | +70°C |
